UNIVERSAL TESTING MACHINE

HOME PRODUCTS  >  UNIVERSAL TESTING MACHINE MODEL MT100 PRO

TENSILE TWIN COLUMN

HIGH-FORCE TESTING SYSTEMS

Model : MT100 PRO

เครื่องทดสอบแรงดึงแรงกด อเนกประสงค์แบบเสาคู่

เป็นเครื่องทดสอบระบบไฟฟ้าที่ออกแบบมาเพื่อทดสอบคุณสมบัติเชิงกลของวัสดุได้หลากหลาย เช่น แรงดึง แรงกด แรงดัด การลอก การฉีกขาด แรงเสียดทาน และแรงเฉือน รองรับการทดสอบตามมาตรฐานสากล เช่น ASTM และ ISO

อีกทั้งยังสามารถใช้งานร่วมกับอุปกรณ์เสริมหลายชนิดเพื่อให้เหมาะกับการทดสอบวัสดุและผลิตภัณฑ์ในหลากหลายรูปแบบ เครื่องรุ่นนี้มีให้เลือกหลายขนาดและการตั้งค่า รองรับงานวิจัยและพัฒนาผลิตภัณฑ์ (R&D) การควบคุมคุณภาพ (QC) และการทดสอบเชิงกลทั่วไป โดยสามารถรองรับแรงได้สูงสุดถึง 30 kN ซึ่งเหมาะสำหรับงานที่ต้องการความแม่นยำและความน่าเชื่อถือในหลากหลายอุตสาหกรรม

What It's For
BRAVO MT100 Pro Series Twin Column electromechanical universal testing machines can perform a wide range of mechanical tests including tensile, compression, bend, peel, tear, friction, and shear testing. These systems are designed to test materials, components, and products in accordance with ASTM, ISO, and other industry standards. Compatible with hundreds of accessories for a wide range of applications, these universal testing systems are available in a multiple sizes and configurations for R&D, QC, and other mechanical testing up to 100 kN force.

What It Does
The BRAVO MT100 Pro Series Twin Column Universal Testing Machine is a high-capacity system designed for tensile, compression, bend, peel, tear, friction, and shear testing. Engineered to meet ASTM and ISO standards, it ensures precise and reliable material testing for various industries. With compatibility for hundreds of accessories, this versatile machine supports R&D, quality control (QC), and mechanical testing, offering multiple configurations and handling forces up to 100 kN for comprehensive material analysis.

The Stealth MT100 Pro Series Universal Testing Machine is a versatile tensile and compression tester controlled by software running on a PC.

  • Load Cell Capacity : 20N - 100KN
  • Panasonic servo motor drive set
  • "USA" Load cell grade 0.05%
  • Force Resolution 1/109 FS
  • Force Measurement rang 0.1% to 100%FS
  • Crosshead speed 0.0001 to 500 mm/min
  • Crosshead Travel 1,050 mm
  • Width Columns 550 mm
  • Data Transfer Rate to PC 1kHz.
  • USB Communication

The Stealth MT100 Pro Series Universal Testing Machine can test a wide range of materials, including

  • Metal
  • Plastic
  • Rubber
  • Textile
  • Synthetic
  • Wire
  • Cable
  • Food
  • Packaging
  • Autopart
  • Spring
  • AeroSpace
  • Woods
  • Composite
  • Etc.
